ReefControl ATO Module
Water type
Marine + Reef
Fits
Red Sea ReefControl Lite, Red Sea ReefControl Pro
Part no.
BA9028
ReefControl ATO Module
Fail-safe auto top-off, built into your controller. The Red Sea ReefControl ATO Module adds a complete automatic top-off system to a ReefControl Lite or Pro controller, without a separate standalone ATO unit to plumb and program. It suits anyone already running ReefControl who wants top-off, temperature logging and overfill protection managed from the same app and hardware as their other probes.
Key features
- Solid-state digital sensor — titanium probe with no moving parts, reporting water level and temperature to ±0.1°C.
- Variable-flow 12V DC pump — up to 300 L/h (75 GPH) at zero head, 2.5m (8') maximum lift.
- Fail-safe logic — shuts the pump down automatically if the sensor disconnects, the pump runs abnormally long, or the RO reservoir runs dry.
- Magnetic mounting bracket included — fits glass up to roughly 12mm thick.
- No standalone controller needed — runs entirely through the ReefControl Lite or Pro you already own.
Specifications
| Pump power | 12V DC, 6–10 W, variable flow |
|---|---|
| Maximum flow | 300 L/h (75 GPH) at zero head |
| Maximum head | 2.5 m (8 ft) |
| Sensor type | Solid-state titanium level and temperature probe |
| Temperature accuracy | ±0.1°C |
| Tubing included | 3 m (10 ft) silicone tubing |
| Requires | Red Sea ReefControl Lite or Pro controller (sold separately) |
| SKU | BA9028 |
What's included
- Digital ATO level and temperature sensor
- 12V DC variable-flow ATO pump
- Magnetic sensor mounting bracket
- 3 m (10 ft) silicone tubing
- Siphon breaker
- Silent-flow tube holder
Not included
- ReefControl Lite or Pro controller — this module only functions connected to one of these
- RO/DI reservoir
- 12VDC power/connector cable to the controller, if not already supplied with your controller
This module does not run stand-alone: it needs an existing ReefControl Lite or Pro base unit to plug into. If you don't already own a ReefControl controller, the standalone ReefATO+ 3-in-1 system is the equivalent product that doesn't require one.
Performance
The pump is rated 300 L/h at zero head, falling off toward its 2.5 m maximum lift — expect meaningfully less delivered flow the higher the top-off point sits above the reservoir. Red Sea has not published a full head-loss curve for this pump, so treat the 300 L/h figure as a best-case, zero-head number rather than what reaches your sump in practice.
Safety
The fail-safe logic disables the pump if the sensor disconnects or the pump runs longer than expected, guarding against a stuck-on pump overflowing the sump. It doesn't replace checking the reservoir level and the ATO's operation periodically yourself.
Warranty and delivery
Covered by Red Sea's manufacturer warranty, which applies in addition to your consumer guarantee rights under Australian Consumer Law. Ships as a standard parcel item.
Common questions
Do I need a ReefControl controller already?
Yes. This module adds ATO functionality to an existing ReefControl Lite or Pro — it has no display or app of its own.
What happens if the sensor loses connection mid-top-up?
The pump shuts down automatically as part of the fail-safe logic, rather than continuing to run unmonitored.
Can I use this instead of the standalone ReefATO+?
Only if you already have a ReefControl controller — the ATO Module has no independent controller of its own, unlike the 3-in-1 ReefATO+, which runs on its own hardware.
What glass thickness does the mounting bracket suit?
Roughly 12mm, matching the bracket used across Red Sea's ReefATO+ sensor range.
