Bioscape All in One Pond Filter Light Pump Unit
Water type
Freshwater
Fits
Bioscape All in One Submersible Pond Filter 2000LPH (BIS670, no UV)
Part no.
BIS670E
Genuine part
Yes, Bioscape spare
Bioscape All in One Pond Filter Light Pump Unit
The complete pump and light assembly for the standard All in One pond filter. This is the genuine pump-and-light unit for the Bioscape All in One Submersible Pond Filter 2000LPH (BIS670, no UV) – the motor, impeller housing and 1 W automatic LED fountain light as one replaceable assembly. It's the right part when the motor itself has failed, not just the impeller.
Key features
- Complete pump-and-light assembly – motor, impeller housing and the automatic LED fountain light, in one replaceable unit.
- No UV connector – built for the standard BIS670, which has no UV-C stage. The UV-equipped BIS671 takes a different assembly; see Bioscape All in One Pond Filter Light Pump and UV Connector.
- Fixes a failed motor – for a jammed or worn impeller alone, the cheaper impeller-and-shaft part is the right fix instead.
Which model does this fit?
| Model | Fits |
|---|---|
| Bioscape All in One Submersible Pond Filter 2000LPH (BIS670, no UV) | Yes |
| Bioscape All in One Submersible Pond Filter with UV 2000LPH (BIS671) | No – needs the UV-connector version instead |
Specifications
| Part number | BIS670E |
|---|---|
| Assembly includes | Pump motor and impeller housing, LED fountain light |
| Water type | Freshwater ponds |
Suitable for, and not suitable for
Suitable for the Bioscape All in One Submersible Pond Filter, standard model BIS670. Not suitable for the UV-equipped BIS671, which needs the version with the UV-C connector fitted.
Care and maintenance
Replace this assembly when the motor itself is faulty – it won't prime, runs noticeably louder than normal, or the LED fountain light no longer works. Check for hair, string algae and grit around the impeller first; a blockage there causes the same symptoms and is fixed by cleaning rather than replacement.
Warranty and delivery
Covered by consumer guarantees under Australian Consumer Law. Runs on the 24 V DC low-voltage side of the All in One unit; the transformer is a separate part. Ships as a standard parcel.
Common questions
How is this different from the impeller and shaft part?
This is the whole pump motor, housing and light. If only the impeller is jammed or worn, the cheaper Impeller with Shaft fixes it without replacing the motor.
Will this fit my BIS671 (UV model)?
No. BIS671 needs the pump-and-light assembly with the UV-C connector fitted. This version has no UV connector and is built for the non-UV BIS670.
My fountain light doesn't come on – is this the fix?
If the pump is running and only the light has failed, check the photosensor isn't shaded or covered in algae first. If the LED itself is dead, this assembly replaces it along with the pump.
